Toyotomi Laser Direct Vent Heaters
The revolutionary TOYOTOMI Laser Direct Vent Heaters, with their whisper-quiet comfort, safety and dependability, are the most popular, best-selling, direct vent heating systems in Alaska. With multiple options to choose from, a Laser Direct Vent Heater can often heat an entire home. It is also the perfect solution for those hard-to-heat room or areas. Laser Heaters are ideal for heating summer homes or cabins, and are certified for installation in mobile homes and manufactured housing. More than half a million satisfied customers trust their home’s heat to TOYOTOMI.
- L-301/302
- L-531/532
- L-731/732
L-301/302
| Part Number: L-301/302 | |
|---|---|
| Fuel Type | ASTM D3699 K1 KEROSENE ASTM D396 NO.1 LOW SULFUR FUEL OIL ASTM D975 ULTRA LOW SULFUR HEATING OIL/ DIESEL |
| Heating Efficiency | 87% (AFUE Rating) |
| Heating Rating | 15,000 BTU/Hr (high) 10,100 BTU/Hr (medium) 5,310 BTU/Hr (low) |
| Fuel Consumption | 0.11 Gal/Hr (High) 0.08 Gal/Hr (Medium) 0.04 Gal/HR (High) |
| Size (WxHxD) | 17-3/8″ x 21-3/4″ x 15-1/8″ |
| Weight | 31 lbs (empty) |
| Heating Area * | 600 Sq. Ft. at (0°F) 720 Sq. Ft. at (20°F) |
| Max. Length of Vent Pipe System |
Maximum 10 Ft., 3 bends or less |
| Electrical Rating | 120 Volts AC, 60 Hz Preheat: 240 Watts Burning: 23 Watts |
| Vent Hole Pipe | 2-3/4″ – 3″ Diameter |
| Type of Tank | Exterior Tank |
* 0° F Heat Load = 24 BTU/ft²/hr
20° F Heat Load = 20 BTU/ft²/hr
Room size for which this heater is suitable will vary depending on outside temperature, house insulation, window size and other factors.
L-531/532
| Part Number: L-531/532 | |
|---|---|
| Fuel Type | ASTM D3699 K1 KEROSENE ASTM D396 NO.1 LOW SULFUR FUEL OIL ASTM D975 ULTRA LOW SULFUR HEATING OIL/ DIESEL |
| Heating Efficiency | 87% (AFUE Rating) |
| Heating Rating | 22000 BTU/Hr (high) 15000 BTU/Hr (medium) 8000 BTU/Hr (low) |
| Fuel Consumption | 0.17 Gal/Hr (High) 0.11 Gal/Hr (Medium) 0.06 Gal/HR (High) |
| Size (WxHxD) | 19-5/8″ x 23-5/8″ x 16-1/2″ |
| Weight | 38 lbs (empty) |
| Heating Area * | 920 Sq. Ft. at (0°F) 1150 Sq. Ft. at (20°F) |
| Max. Length of Vent Pipe System |
Maximum 10 Ft., 3 bends or less |
| Electrical Rating | 120 Volts AC, 60 Hz Preheat: 240 Watts Burning: 48 Wattts |
| Vent Hole Pipe | 2-3/4″ – 3″ Diameter |
| Type of Tank | Exterior Tank |
* 0° F Heat Load = 24 BTU/ft²/hr
20° F Heat Load = 20 BTU/ft²/hr
Room size for which this heater is suitable will vary depending on outside temperature, house insulation, window size and other factors.
L-731/732
| Part Number: L-731/732 | |
|---|---|
| Fuel Type | ASTM D3699 K1 KEROSENE ASTM D396 NO.1 LOW SULFUR FUEL OIL ASTM D975 ULTRA LOW SULFUR HEATING OIL/ DIESEL |
| Electric Rating | AC 120V, 60Hz |
| Heating Efficiency | 87% (AFUE Rating) |
| Heating Rating | 40000 BTU/Hr (high) 27000 BTU/Hr (medium) 15000 BTU/Hr (low) |
| Size (WxHxD) | 30″ x 27-1/2″ x 16-3/4″ |
| Weight | 75 lbs (empty) |
| Fuel Consumption | 0.30 gal/hr (high) 0.20 gal/hr (medium) 0.11 gal/hr (low) |
| Heating Area * | 1670 Sq. Ft. at (0°F) 2000 Sq. Ft. at (20°F) |
| Max. Length of Vent Pipe System |
Maximum 10 ft., 3 bends or less |
| Electrical Rating | 120 Volts, 60 Hz Preheat: 260 Watts Burning: 54 Watts |
| Vent Hole Pipe | 2-3/4″ – 3″ diameter |
| Type of Tank | Exterior Tank |
* 0° F Heat Load = 24 BTU/ft²/hr
20° F Heat Load = 20 BTU/ft²/hr
Room size for which this heater is suitable will vary depending on outside temperature.
